Dock station B-Dock
– Edge rounding function, beveling of pipes
(Maximum bevel width 5 mm / 0.2 in.)
Dock station B-Dock enables the B10 Electra or B15 Electra to be used stationary.
It is deigned for beveling small workpieces which would be hard or impossible to clamp and bevel the standard way.
The system retains all advantages of the hand-held machine B10 Electra or B15 Electra.
The B-Dock system makes it possible to bevel irregular shapes, straight workpieces and holes.
Radiuses edges are also possible with the radius milling head.
Specialty guide attachments and an easy, vertical worktable adjustment allow for beveling of pipe and tube.
By purchasing the set B-Dock + B10 Electra or B15 Electra you are getting a universal beveling system.
The B10 Electra or B15 Electra can be used independently from the B-Dock as a hand-held beveling machine.
- Tilting table for easy attachment of B10 Electra or B15 Electra
- Vertical position of the table for convenient pipe beveling
- Straight edge and pipe guide attachments included in the price
- Adjustable protection shield increases work safety
- Robust design insures precision beveling and durability of the B-Dock
- The Hardox work sufrace is wear resistant
- Light weight system is easy to transport
- Can be used with B10 Electra or B15 Electra machines
- Manufactured in Czech Republic
Technical data:
- Max. bevel width B-Dock + B10 Electra or B15 Electra:
0 to 5 mm / 0 to 0.2 in
- Bevel angle:
replaceable head 0° / 30° / 37,5° / 45° / 50° / 60° – other angles on demand
- Rounding Radius:
R 2,5 mm / R 3,5 mm / R 4 mm
R0.08″ / R0.12″ / R0.16″
- Motor: according to the selected machine
- Speed:according to the selected machine
- Feeding: manual
- Weight B-Dock: 28 kg / 62 lb
Included it the price:
- Dock station B-Dock
- Packet in a cardboard
- Operating tools
- User manual
| Machine name: | 1Phase-230V | 1Phase-120V |
| Dock station B-Dock (beveler B10 Electra / B15 Electra is not included) | 25350 | 25350 |
| SET Bevelling system B10 ELECTRA + dock station B-Dock (without the milling head) | 25302 | 25303 |
| SET Bevelling system B15 ELECTRA + dock station B-Dock (without the milling head) | 25252 | 25253 |
| SET Bevelling system B10 ELECTRA + dock station B-Dock + Xpipe Beveler (without the milling head) | 25305 | 25307 |
| SET Bevelling system B15 ELECTRA + dock station B-Dock + Xpipe Beveler (without the milling head) | 25255 | 25257 |
| Accessories – PREMIUM milling heads: | Art.Nr. |
| 30° milling head PREMIUM – the cutting inserts and the lead roller Ø 30 mm / 1.19“are included | 27223X |
| 37,5° milling head PREMIUM – the cutting inserts and the lead roller Ø 26 mm / 1.02“ are included | 27227X |
| 45° milling head PREMIUM – the cutting inserts and the lead roller Ø 26 mm / 1.02“ are included | 27222X |
| 50° milling head PREMIUM – the cutting inserts and the lead roller Ø 26 mm / 1.02“ are included | 27224X |
| 60° milling head PREMIUM – the cutting inserts and the lead roller Ø 19 mm / 0.75“ are included | 27240X |
| The additional special roller 30° for shorter cutting inserts 8 mm / 0.3“ – diameter Ø 33,5 mm / 1.32“ | 28004 |
| The additional special roller 37,5° for shorter cutting inserts 8 mm / 0.3“ | 28013 |
| The additional special roller 45° for shorter cutting inserts 8 mm / 0.3“ – diameter Ø 31 mm / 1.23“ | 28005 |
| The additional special roller 50° for shorter cutting inserts 8 mm / 0.3“ | 28014 |
| The additional special roller 60° for shorter cutting inserts 8 mm / 0.3“ – diameter Ø 25,5 mm / 1.01“ | 28006 |
| The spare two sided cutting inserts 15 mm / 0.6“ – two-sided, coated – pack of 10 pcs – only for premium milling heads | 28015 |
| The shorter four sided cutting inserts 8 mm / 0.3“ – four-sided, coated – pack of 10 pcs – only for premium milling heads with additional special roller | 28008 |
| The fastening screws for cutting inserts (works with both cutting inserts versions) – only for premium milling heads | 28007 |
| Accessories – Edge cleaner – grinding adapter: | Art.Nr. |
| Edge Cleaner – grinding adapter – including 10 pcs grinding rings grain 40, 1 pc guiding roller | 25310 |
| Grinding rings grain 40 for Edge Cleaner – pack of 50 pcs | 25312 |
| Spare polyurethane guiding roller for Edge Cleaner | 25311 |
| Accessories – The Rounding milling heads: | Art.Nr. |
| Complete radius milling head R2,5 mm / 0.08“ – including of the guiding roll and fastening screw, the cutting inserts are included – the lead roller diameter Ø 30 mm / 1.19“ | 27234 |
| Complete radius milling head R3,5 mm / 0.12“ and R4 mm / 0.16“ – including of the guiding roll and fastening screw, the cutting inserts R3,5 mm / 0,12“ are included – the lead roller diameter Ø 39,5 mm / 1.55“ | 27233 |
| Cutting inserts for rounding edges R2,5 mm / 0.08“ – four-sided – pack of 10 pcs | 26109 |
| Coated cutting inserts for rounding edges R3,5 mm / 0.12“ – four-sided – pack of 10 pcs | 26110 |
| Coated cutting inserts for rounding edges R4 mm / 0.16“ – four-sided – pack of 10 pcs | 26111 |
| The fastening screws for cutting inserts – only for rounding milling heads | 27242 |
| Accessories – The older ECO milling heads. Available while supplied last. | Art.Nr. |
| 30° cutting head – including inserts, screws, bolts and roller – guide roller diameter Ø 34 mm / 1.34“ | 27223 |
| 37,5° cutting head – including inserts, screws, bolts and roller – guide roller diameter Ø 28 mm / 1.10“ | 27227 |
| 45° cutting head – including inserts, screws, bolts and roller – guide roller diameter Ø 28 mm / 1.10“ | 27222 |
| 50° cutting head – including inserts, screws, bolts and roller – guide roller diameter Ø 28 mm / 1.10“ | 27224 |
| 60° cutting head – including inserts, screws, bolts and roller – guide roller diameter Ø 27 mm / 1.06“ | 27240 |
| Cutting head with non-standard angle – including inserts, screws, bolts and roller | 27XXX |
| Coated cutting inserts – four-sided – pack of 10 pcs – only for ECO milling heads | 27231 |
| Screw for the cutting inserts – only for ECO milling heads | 27241 |
| Accessories – others: | Art.Nr. |
| Dock station B-Dock (beveler B10 Electra / B15 Electra is not included) | 25350 |
| Xpipe Beveler – bevelling tool for machining of pipes from Ø 85 mm / 3.36“ (beveler B10 Electra / B15 Electra / B15 AIR is not included) | 25500 |
| Special lubricating paste for the milling heads 120g – prevents seizing up, wear, cold-welding, solidifying of the threads | 33005 |
| Mag Brush Maxx Large – magnetic sweeper equipped with wheels for collecting all magnetic materials – working width 450 mm / 17.71 in | NMF0107 |
| Mag Brush – collects all magnetic | 18654 |
